GS-4047
Equipment type:
Increase productivity in high rise spaces with the Genie® GS™-4047 slab scissor Lift thanks to its ability to be driven at full height and designed for excellent maneuverability in tight spaces and narrow aisles.
General
Manufacturer: Genie
Model(s): GS-4047
Capacity: 550 lbs
Dimensions
Capacity: 550 lbs
Machine Length: 8 ft 2 in | 2.48 m
Machine Width: 3 ft 11 in | 1.19 m
Max Platform Height: 39' | 11.89 m
Platform Height: 39' | 11.89 m
Weight: 7,185 lb | 3,260 kg
Working Height: 44' 11” | 13.70 m
Engine
Operational
Features
- 25% gradient to get up slopes and loading ramps
- 3-ft (0.91 m) extension deck maximum platform workspace
- Compact dimensions for easily passing through Standard double doors
- Front-wheel drive and zero inside turning radius
Options
- Air line to platform: ? in inner diameter
- Automotive-style horn
- Certification Options
- Chassis Options
- EE Certification
- Platform Options
- Power inverter, 800W, 24V DC, 120V AC, 60 Hz
